SIBA 160516.6,3GT SMD fuse SMD 6.30 A 125 V DC/AC Time delay -T- 1 pc(s)
Product type
SMD fuse
Nominal voltage
125 V DC/AC
Nominal current - rounded value
6.3 A
Release characteristics
Time delay -T-
Type
SMD
Datasheet (PDF)
Part number:
Item no:
Highlights & Details
SIBA SMD-fuse 160516 slow-blow 1,500A 305VAC 6,3A 17,5X7,4mm with clip holder
- SMD fuse with clip
- slow-blow
- Very compact design: 4.5x16mm fuse (with clip: 7.4x17.5mm)
- Ceramic tube with filling
- Safety clip: Tin-plated bronze
- Soldering heat resistance (according to IEC60068): 260°C, 10s
- REACH Art. 33: Contains lead CAS# 7439-92-1
Technical specifications
- Casing material: Ceramic
- Material of connectors: Brass, silver-plated
- Melting Integral: 4.8 A²/s.
- Rated breaking capacity 50 A.
- Voltage drop 130 mV
- Soldibility 260 °C / 10 s
- Product type
SMD fuse
- Nominal voltage
125 V DC/AC
- Dim
(L x W x H) 17.5 x 7.4 x 6.4 mm
- Nominal current - rounded value
6.3 A
- Nominal current
6.30 A
- Release characteristics
Time delay -T-
- Type
SMD
- Length
17.5 mm
- Width
7.4 mm
- Height
6.4 mm
- Content
1 pc(s)
- Type
160516.6,3GT
- Certification marks
IEC 60127-4/2, UL 248-14
- Weight
1.5 g
Documents & Downloads
Datasheet
Datasheet 3842409 SIBA 160516.6,3GT SMD fuse SMD 6.30 A 125 V DC/AC Time delay -T- 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3842409 SIBA 160516.6,3GT SMD fuse SMD 6.30 A 125 V DC/AC Time delay -T- 1 pc(s)
Description
For protection of devices and modules against high over and short circuit currents up to 4000A, such as a mains fuse.
