SIBA 7012540.1,25 SF SMD fuse 1.25 A 305 V AC Very quick acting -FF- Content 10 pc(s)
Product type
SMD fuse
Nominal voltage
305 V AC
Nominal current - rounded value
1.25 A
Release characteristics
Very quick acting -FF-
Content
10 pc(s)
Datasheet (PDF)
Part number:
Item no:
Highlights & Details
SIBA G-fuse link 6.3X32 mm 7012540 super-quick-blow 700VAC 1.25A
- Ceramic tube, opaque with solvent filling
Technical specifications
- Casing material: Ceramic
- Melting Integral: 170 A²/s.
- Rated breaking capacity 1,500 A.
- Voltage drop 120 mV
- Soldibility 260 °C / 10 s
- Product type
SMD fuse
- Nominal voltage
305 V AC
- Nominal current
1.25 A
- Nominal current - rounded value
1.25 A
- Release characteristics
Very quick acting -FF-
- Content
10 pc(s)
- Type
7012540.1,25 SF
- Weight
2.6 g
Documents & Downloads
Datasheet
Datasheet 3843499 SIBA 7012540.1,25 SF SMD fuse 1.25 A 305 V AC Very quick acting -FF- Content 10 pc(s)
User & Safety Instructions
User & Safety Instructions 3843499 SIBA 7012540.1,25 SF SMD fuse 1.25 A 305 V AC Very quick acting -FF- Content 10 pc(s)
Description
As primary protection in devices
