Siemens 3RQ1000-2HW00-0AX0 Crossbar switch 2 makers 1 pc(s) Piece
Packaging type
Piece
Product type
Crossbar switch
Contact type
2 makers
Switching voltage (max.)
240 V DC/AC
Connection
Spring-loaded connector
EAN:
Part number:
Item no:
Highlights & Details
Positively driven relay, 2S+2Ö, AC/DC 24-240V, spring-loaded connector, SIL 2/PL c
Our service for you
Technical specifications
- Packaging type
Piece
- Product type
Crossbar switch
- Type
3RQ1000-2HW00-0AX0
- Contact type
2 makers
- Switching voltage (max.)
240 V DC/AC
- Connection
Spring-loaded connector
- Features
+ enclosure
- Width
17.5 mm
- Content
1 pc(s)
- RoHS-compliant
Yes
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3402984 Siemens 3RQ1000-2HW00-0AX0 Crossbar switch 2 makers 1 pc(s) Piece
Description
Positively driven coupling relay in industrial housing 2 NO contact / 2 NC contact 24 V to 240 V AC/DC protective-coated PCB SIL 2 / PL c spring-type connection (push-in) Positively driven SIRIUS 3RQ1 coupling relay for fail-safe coupling of control signals to and from a control system and for the contact extension of 3SK safety relays. The 3RQ1 positively-guided coupling relays have a safety certification and can be connected to the 3SK safety relays. Thanks to the wide-range input they can be used universally. Detachable clamps enable easy exchange of devices and quick wiring. Devices with safety certification up to SIL 3/PL e are available, with single and wide-voltage ranges, different contact versions, also in width 17.5 mm, each with screw or spring-type connection (push-in). SIRIUS relay - a program for all cases.
