Siemens 3SU18010BD004AB1 3SU1801-0BD00-4AB1 Enclosure for floor mounting, Front ring (steel) 1-button Clear, Silver 1 pc
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Number of command points: 1
- Actuator type: Pushbutton
- Design of the contact / the auxiliary contacts: Silver alloy
- Case mounting method: Vertical
- Equipment protection class II.
- OPERATING VOLTAGE 5 500 V DC/AC
- Brightness 900 - 1400 mcd
- Actuator material: Metal
- Case material: Plastic
- Material of holder: Metal
- Packaging type
Piece
- Product type
Enclosure
- Switch/button features
for floor mounting
Front ring (steel)
- Lighting type
LED
- Bulb type
LED (monochrome)
- Operation type
1-button
- Colour
Clear
- Factory colour
Clear
Silver
- Case colour
Grey
- Print motif
I
- Connection
Open cable end
Spring-loaded connector
- Shape
Mounting hole: Round; front of housing: Square; actuator: Round
- Functions
momentary
- Contact type
1 maker
- Recess diameter
22.5 mm
- Type
With recess for label
IP66
IP67
IP69/IP69K
- Min. temperature
-25 °C
- Max. temperature
+70 °C
- Width
85 mm
- Height
85 mm
- (Ø)
22 mm
- Content
1 pc(s)
- Dim
(Ø x H) 22 mm x 85 mm
- RoHS-compliant
Yes
- Depth
75 mm
- Type
3SU1801-0BD00-4AB1
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 2864012 Siemens 3SU18010BD004AB1 3SU1801-0BD00-4AB1 Enclosure for floor mounting, Front ring (steel) 1-button Clear, Silver 1 pc
User & Safety Instructions
User & Safety Instructions 2864012 Siemens 3SU18010BD004AB1 3SU1801-0BD00-4AB1 Enclosure for floor mounting, Front ring (steel) 1-button Clear, Silver 1 pc
Description
Casing for control devices 22 mm, round, housing material plastic, housing top part gray, 1 command point, A = illuminated pushbutton, clear, metal, 1S, LED 24V, Spring-loaded connection, floor mounting, support point terminal, shield: I, top and bottom 1xM20 housing SIRIUS ACT for mounting the 22.5 mm command and signaling devices in a spatially separate arrangement of control units and control cabinets.
Under the brand name SIRIUS ACT, Siemens offers a unique portfolio of control and signaling devices with worldwide product approvals in three modern design series made of robust real metal and high-quality plastic.
The innovative snap concept simplifies the mounting so that only one hand and no special tool are needed. As installation holes, slot-free holes are sufficient, since a 100% anti-twist protection is already integrated.
Thanks to the consistently high degree of protection, the robust devices are suitable for industrial use and for outdoor use. Even high-pressure cleaning is possible. Neither dust, oil nor aggressive alkalis can disturb the reliable operation.
In addition to the standard wiring, most devices can also be connected to the controller via PROFINET, AS-Interface or IO-Link. This reduces your wiring work, minimizes the sources of errors and gives you more flexibility.
The graphical online configurator conveniently supports the selection and ordering of individual devices, enclosures and labels. Extensive documentation (e.g. manual, 3D data, connection diagram) is available.
Available designs: Yellow/gray, plastic/metal, 1-6 command points, empty housing/pre-mounting, optionally with AS-interface connection.
SIRIUS ACT - Performance in ACTION for commands and messages. Simply mounted, simply strong, simply perfect.
