Siemens A5Q00014104 A5Q00014104 Storey control panel 1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Operating voltage 12…32 V DC
- Supply voltage: DC 20...30 V.
- AC 15…18 V (external power input)
- Power consumption: 5 mA @ 24 V (standby current, LCD illumination inactive)
- 45 mA @ 24 V (maximum current, LCD illumination active)
- Cable size 0.8...1.5 mm²
- Communication protocol: FDnet/C-NET
- System compatibility: FDnet -> FS20
- C-NET> - FS720
- IP30 protection
- Operating temperature -8…42 °C.
- Storage temperature: -20...+60 °C.
- Relative humidity: ≤95 % rel. (no condensation)
- Color: Light gray, ~RAL 7035
- Dimensions (W x H x D) 282 x 207 x 79 mm
- Number of addresses: 1
- Standard EN 54-17
- EN 54-18
- Accessories: FHA2013-A1 rear panel (FT201x flat)
- Product type
Storey control panel
- Operating voltage
12...32 V DC
- Content
1 pc(s)
282
207 mm
79 mm
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 2483140 Siemens A5Q00014104 A5Q00014104 Storey control panel 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2483140 Siemens A5Q00014104 A5Q00014104 Storey control panel 1 pc(s)
Information
Information 2483140 Siemens A5Q00014104 A5Q00014104 Storey control panel 1 pc(s)
Description
Floor display and HMI device with backlit large display with plain text display (6 lines with 40 characters each) for addressed Sinteso FS20 and Cerberus PER FS720 fire alarm system.
A clear and clear user interface for customer-specific plain texts is available to the responsible customer personnel for the clear localization of events. Sections and groups that can be operated and displayed via the floor terminal can be configured. Display of alarms, pre-alarms, technical messages, faults, shut-down possible. Use the navigation keys to scroll through the displayed list. Acknowledge and reset events. The event text is identical to the fire panel or fire panel terminal. Nordic key switch for operating access.
Power supply via FDnet/C-NET, separate 24 V supply possible.
The floor terminal can be operated in loops or in stub lines.
This text is machine translated.
A clear and clear user interface for customer-specific plain texts is available to the responsible customer personnel for the clear localization of events. Sections and groups that can be operated and displayed via the floor terminal can be configured. Display of alarms, pre-alarms, technical messages, faults, shut-down possible. Use the navigation keys to scroll through the displayed list. Acknowledge and reset events. The event text is identical to the fire panel or fire panel terminal. Nordic key switch for operating access.
Power supply via FDnet/C-NET, separate 24 V supply possible.
The floor terminal can be operated in loops or in stub lines.
This text is machine translated.
