Siemens KNX 5WG15622SB32 Gateway 5WG1562-2SB32
EAN:
Part number:
Item no:
Technical specifications
- Product type
Gateway
- Series
KNX
- Max. switching capacity
3680 VA
- Used at
Indoors
- Operating voltage
230 V AC
- Data transfer (Smart Home)
Wired
- Channels
3
- Mounting type
Flush mount
- Hub
Not required, optional for remote access
- Data exchange
Bidirectional (bi)
- Features
Signal input
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3403622 Siemens KNX 5WG15622SB32 Gateway 5WG1562-2SB32
Description
- One relay contact per output - Contact rated operating voltage: AC 230 V - Contact rated frequency: 50 / 60 Hz - Contact rated current: ∑ 16 A - Screw terminals for connection of untreated conductors single-wire, fine-wired without wire-end sleeve 0.5 to 4 mm², fine-wired with wire-end sleeve 0.5 to 2.5 mm² - 3 binary inputs for potential-free contacts, determination of the switching state via voltage generated in the device - inquiry voltage of the inputs: approx. 5 V - Max. 10 m length of connecting cables, preferably J-Y(St)Y, pre-assembled YY6x0.6 - Operation of electronics via bus voltage - Integrated bus coupler - Mounting in device sockets according to DIN 49073 or in mounting case M 592/01 (accessories)
