Siemens S54370F10A1 FDCAI221 Alarm indicator 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Operating temperature -10…55 °C.
- Standard: EN 54-17
- EN 54-18
- Relative humidity: ≤95 % rel.
- Protection class: IP40
- Operating voltage 12…33 V DC
- Communication protocol: FDnet/C-NET
- Standby current 240...400μA
- Dimensions (W x H x D) 85 x 85 x 32 mm
- Color: Pure white, ~RAL 9010
- Accessories: AI330 additional frame
- Product type
Alarm indicator
- Operating voltage
12...33 V DC
- Content
1 pc(s)
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 2483093 Siemens S54370F10A1 FDCAI221 Alarm indicator 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2483093 Siemens S54370F10A1 FDCAI221 Alarm indicator 1 pc(s)
Information
Information 2483093 Siemens S54370F10A1 FDCAI221 Alarm indicator 1 pc(s)
Description
The addressable alarm indicator is used for visual display of automatic fire detectors. It enables the quick detection of alarm-giving detectors, which are difficult to access or are poorly visible or not immediately visible. The alarm indicator contains two LEDs that light up as soon as the associated detector alarms.
Screwless terminals.
The alarm indicator is suitable for wall mounting.
