Socket enclosure 09 40 134 0951 09401340951 HARTING 1 pc(s) Piece
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Socket enclosure
Case material
Aluminium, die cast
Type
09 40 134 0951
Manufacturer part #
09401340951
Datasheet (PDF)
Technical specifications
- Type of locking: Screw lock
- Temperature limit: -40 ... +125 °C
- Net weight: 1,316 g
- Note: Mounting cover is absolutely necessary! Please order separately.
- Fire protection in rail vehicles: EN 45545-2 (2020-08)
- Range of uses: Housing for harsh outdoor use
- Material locking: Stainless steel
- Protection class according to IEC 60529: IP65;IP68;IP69 / IPX9K according to ISO 20653
- Tightening torque: 6 Nm mounting cover;15 Nm PE screw;6 Nm mounting screws
- Frame size 34 HPR
- Casing type: Base casing
- Housing series: HAN® HPR EasyCon
- Material housing: Aluminium die-cast; corrosion-resistant
- Surface of housing: Powder-coated
- Colour of housing: RAL 9005 (jet black)
- Material sealing: NBR
- Limit temperature note: When used as a connector in accordance with IEC 61984.
- Tightening torque screw locking: 4 Nm
- Packaging type
Piece
- Type
09 40 134 0951
- Product type
Socket enclosure
- Manufacturer part #
09401340951
- Features
+ screw lock
- Case material
Aluminium, die cast
- Series
Han® HPR EasyCon
- Content
1 pc(s)
IP65
IP68
IP69
IPX9K
- Max. temperature
+125 °C
- Min. temperature
-40 °C
TRUE
FALSE
Black
Screw
FALSE
FALSE
Aluminium
Powder coating
-40-125 °C
Other
FALSE
TRUE
Socket case
IP65
Other
None
None
Documents & Downloads
Datasheet
Datasheet 3006119 Socket enclosure 09 40 134 0951 09401340951 HARTING 1 pc(s) Piece
Datasheet 3006119 Socket enclosure 09 40 134 0951 09401340951 HARTING 1 pc(s) Piece
User & Safety Instructions
User & Safety Instructions 3006119 Socket enclosure 09 40 134 0951 09401340951 HARTING 1 pc(s) Piece
Description
Socket housing, size: 34 HPR, screw locking, stainless steel, material housing: Aluminum die casting, corrosion-resistant, powder-coated
