Solenoid Connectors Black SAIL-VSBD-M12G-3.0U 9457780300 Weidmüller Content: 1 pc(s)
EAN:
Part number:
Item no:
Product type
Square connector
Type
B standard
Connection
Plug
IP rating
IP67 (when locked)
Number of pins
3
Datasheet (PDF)
Highlights & Details
Solenoid Connectors
- SAIL-VSBD-M 12 G 3.0 U
Technical specifications
- Contact surface: Tin-plated
- Nominal current: 4 A
- Sheath material: PUR
- Tightening torque: M3 Mounting screw: 0.4 Nm, M12: 0.8 - 1.2 Nm
- Product type
Square connector
- Type
B standard
- Connection
Plug
IP67 (when locked)
- Number of pins
3
- Nominal voltage
24 V
- Display
LED
- Total no. of pins
3
- Weight
195 g
- Manufacturer part #
9457780300
- Factory colour
Black
- Content
1 pc(s)
- Cable length
3.00 m
- Cable cross section
0.5 mm²
- RoHS-compliant
Yes
- Circuit layout description
incl. diode
- Connector type
Plug, right angle
- Max. temperature
+80 °C
- Min. temperature
-25 °C
- Type
SAIL-VSBD-M12G-3.0U
- Features
Suitable for drag chains
Halogen-free
- Fastening type
M12
- Cable colour
Black
- Connector standard
Sensor connector
- Jacket material
PUR
- Coding
B
- Connection side A
M12 plug, straight
- Connection side B
M12 plug, straight
- Thread type connection side
M12
- Nominal current
4 A
- Cross-section (sensor/actuator wiring)
0.5 mm²
- Cable diameter (details)
4.60
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 260337 Solenoid Connectors Black SAIL-VSBD-M12G-3.0U 9457780300 Weidmüller Content: 1 pc(s)
User & Safety Instructions
User & Safety Instructions 260337 Solenoid Connectors Black SAIL-VSBD-M12G-3.0U 9457780300 Weidmüller Content: 1 pc(s)
Description
Valve plug. Straight plug, BD. Weidmüller offers valve plug as a connection cable with M12 plugs and with free cable end. The operating state of the valve plug is used by a display element (LED) lights. The valve plug, all a protective circuit. The Weidmüller products include valve plug of the types A, B, C according to DIN and industry standard. The protection class IP67 is when mated. The outlet direction is also crucial. At Weidmüller are 0 degrees versions available, that is, the cable outlet direction, the PE contact.
This text is machine translated.
This text is machine translated.
