Solenoid Connectors SACC-VB-3CON-M16/A 1452123 Phoenix Contact Content: 1 pc(s)
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Square connector
Type
A standard
IP rating
IP65 (when installed)
Number of pins
3
Datasheet (PDF)
Technical specifications
- Suitable for cable cross-sections of 0.25–1.5 mm²
- Operating temperature
- Flammability class of insulation material according to UL94: HB
- For cable outside diameter 6-8 mm
- Min Number of mating cycles: 50
- With PE connection: No.
- With status display: No.
- Pollution level 3
- Packaging type
Piece
- Product type
Square connector
- Type
A standard
IP65 (when installed)
- Number of pins
3
- Total no. of pins
3
- Manufacturer part #
1452123
- Content
1 pc(s)
- Cable cross section
0.25-1.5 mm²
- max. cross section
1.5 mm²
- Min. cross section
0.25 mm²
- Connector type
Cable gland
- Max. temperature
60 °C
- Min. temperature
-25 °C
- Type
SACC-VB-3CON-M16/A
- Fastening type
M16
- Leading contact (PE)
No
- Test current
10 A
- Rated voltage
230 V
Documents & Downloads
Datasheet
Datasheet 3453259 Solenoid Connectors SACC-VB-3CON-M16/A 1452123 Phoenix Contact Content: 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3453259 Solenoid Connectors SACC-VB-3CON-M16/A 1452123 Phoenix Contact Content: 1 pc(s)
Description
Square connector, universal, 3-pin, valve connector A, screw connection, Cable gland M16, cable outside diameter 6 mm ... 8 mm
