StandexMeder Electronics MK15-C-1 Reed switch 1 maker 180 V DC/AC 0.5 A 10 W
Product type
Reed switch
Contact type
1 maker
Switching voltage (max.)
180 V DC/AC
Switching current (max.)
0.5 A
Connection
SMD
Datasheet (PDF)
Part number:
Item no:
Highlights & Details
Standex electronics reed sensor MK15 SPST-NO 0.5A 180V 10W AT15...20 SMD
- Suitable for low-Power applications
- Powerful switching element
- Soldering temperature, max. 260°C/5s
- This text is machine translated.
Our service for you
Technical specifications
- Contact: SPST-NO
- Decay time 0.05 ms
- Insulation resistance: 10⁹ ohm
- Static contact resistance, max. 150 mOhm
- Attraction excitation [AT]: 15...20
- Switching time including bouncing: 0.5 ms
- Product type
Reed switch
- Type
MK15-C-1
- Contact type
1 maker
- Switching voltage (max.)
180 V DC/AC
- Switching current (max.)
0.5 A
- Max. switching capacity
10 W
- Connection
SMD
- RoHS-compliant
Yes
- Operating temperature
-40-130 °C
- Weight
0.2 g
