Striebel & John 2CPX035004R9999 KA4604 Meter / transformer board Recess-mount No. of partitions = 12 No. of rows = 0 Con
EAN:
Part number:
Item no:
Product type
Meter / transformer board
No. of partitions
12
No. of rows
0
Mounting type
Recess-mount
Width
250 mm
Datasheet (PDF)
Technical specifications
- Product type
Meter / transformer board
- No. of partitions
12
- No. of rows
0
- Mounting type
Recess-mount
- Factory colour
Grey
- Width
250 mm
- Height
1050 mm
- Dim
(W x H) 250 mm x 1050 mm
- Content
1 pc(s)
Grey
250 mm
eHZ
1050 mm
7035
FALSE
300 mm
TRUE
12
0
0
1
With bus bar 5-pole
IP2XC
80 A
Closed with prestamping
Documents & Downloads
Datasheet
Datasheet 3118328 Striebel & John 2CPX035004R9999 KA4604 Meter / transformer board Recess-mount No. of partitions = 12 No. of rows = 0 Con
User & Safety Instructions
User & Safety Instructions 3118328 Striebel & John 2CPX035004R9999 KA4604 Meter / transformer board Recess-mount No. of partitions = 12 No. of rows = 0 Con
Description
The measuring and converter fields of the KA series with eHZ mounting are intended for installation in the Comfortline cabinet. The fields are pre-wired, which ensures quick and easy installation in the cabinet. The optional busbar connector allows the cross-wiring of several fields to be realized at will. APPLICABLE STANDARDS: DIN EN 61439-1, VDE 0660-600-1, DIN EN 61439-2, VDE 0660-600-2, DIN EN 61439-3, VDE 0660-600-3.
This text is machine translated.
