Striebel & John 2CPX041786R9999 MBT245 Switch disconnector fuse module
Product type
Switch disconnector fuse module
Number of pins
3
Dim
(L x W x H) 750 x 500 x 750 mm
Content
1 pc(s)
Size
NH2
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Product type
Switch disconnector fuse module
- Number of pins
3
- Dim
(L x W x H) 750 x 500 x 750 mm
- Content
1 pc(s)
- Size
NH2
- Width
500 mm
- Height
750 mm
- Length
750 mm
- Depth
225 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2328615 Striebel & John 2CPX041786R9999 MBT245 Switch disconnector fuse module
User & Safety Instructions
User & Safety Instructions 2328615 Striebel & John 2CPX041786R9999 MBT245 Switch disconnector fuse module
Description
Interior fittings module, CombiLine, kit unassembled, for NH2 fuse switch disconnectors, 5 RE latching unit = 750 mm, field width 2 = 500 mm, 120 space units, unfitted for the installation of 4 NH2 LV HRC fuse switch disconnectors, for 3-pole busbar system, rated current in max. 630 A, plastic covers, 90 degree pressure twist lock, RAL 7035, cover version: With cut-out, can be used from a cabinet depth of 225 mm, WR mounting frame must be ordered separately
