Striebel & John 2CPX042248R9999 NH fuse isolator 3-phase Suitable for Fuse size 000 - 4 Fuse size = 1 400 V 1 pc(s)
EAN:
Part number:
Item no:
Product type
NH fuse isolator
Fuse size
1
Number of pins
3
Dim
(L x W x H) 750 x 500 x 750 mm
Content
1 pc(s)
Datasheet (PDF)
Technical specifications
- Product type
NH fuse isolator
- Fuse size
1
- Number of pins
3
- Dim
(L x W x H) 750 x 500 x 750 mm
- Content
1 pc(s)
- Model
3-phase
- Size
NH1
- Nominal voltage
400 V
- Suitable for
Fuse size 000 - 4
- Width
500 mm
- Height
750 mm
- Length
750 mm
- Depth
192 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2329721 Striebel & John 2CPX042248R9999 NH fuse isolator 3-phase Suitable for Fuse size 000 - 4 Fuse size = 1 400 V 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2329721 Striebel & John 2CPX042248R9999 NH fuse isolator 3-phase Suitable for Fuse size 000 - 4 Fuse size = 1 400 V 1 pc(s)
Description
Interior fittings module, CombiLine, mounted in the cabinet, for busbar system 185 mm NH-switch disconnectors, 5 RE latching unit = 750 mm, field width 2 = 500 mm, 120 space units, usable width of 400 mm, equipped with 4 NH fuse switch disconnectors NH1, equipment manufacturer: ABB, inline II ZHBM, for busbar 3-pole, alignment of busbars: Horizontal, With ZX522 busbar holder, busbar center distance: 185 mm, for a maximum of 3 Cu rails, (busbars must be ordered separately), rated current in max. 850 A, plastic covers, 90 degree pressure-twist lock, RAL 7035, cover design: With cut-out, can be used from a cabinet depth of 275 mm, WR mounting frame must be ordered separately
