SWG Hox 17901303067 Countersunk screws 3 mm 30 mm Star DIN 18360 Steel zinc plated 200 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
SWG Hox 17901303067 wood screw 3x30mm HX10 internal drive
- The slim nominal diameter of 3 mm minimizes the risk of fissions when screwed in wood and makes clean connections possible. The nominal length of 30 mm ensures secure thread penetration in common table-top components for a reliable mounting. The HX10 internal drive reduces cam rotation during machine or manual assembly, speeding up installation. Supplied as a 200 piece pack, Ideal for repeated assembly without frequent refilling.
Technical specifications
- Product type
Countersunk screws
- Drive
Star
- Material
Steel
- Thread size
3 mm
- (Ø)
3 mm
- Length
30 mm
- Head shape
Countersunk
- Dim
(Ø x L) 3 mm x 30 mm
- DIN standard
DIN 18360
- Content
200 pc(s)
- Material properties
zinc plated
Documents & Downloads
Datasheet
Datasheet 3595212 SWG Hox 17901303067 Countersunk screws 3 mm 30 mm Star DIN 18360 Steel zinc plated 200 pc(s)
User & Safety Instructions
User & Safety Instructions 3595212 SWG Hox 17901303067 Countersunk screws 3 mm 30 mm Star DIN 18360 Steel zinc plated 200 pc(s)
Information
Test Summary Report 3595212 SWG Hox 17901303067 Countersunk screws 3 mm 30 mm Star DIN 18360 Steel zinc plated 200 pc(s)
Conformity certificate
Conformity certificate 3595212 SWG Hox 17901303067 Countersunk screws 3 mm 30 mm Star DIN 18360 Steel zinc plated 200 pc(s)
Description
This wood screw is used for fixing wood components. It converts the torque into axial clamping force via its threaded shaft and the internal HX10 drive. When the screw is screwed into the wood, the thread cuts or displaces the wood fibers and thus forms a gripping path. This creates a mechanical connection between the parts. The internal drive allows the use of compatible bits for low-slip torque transfer, making Ideal suitable for repeated carpentry or assembly operations requiring even turning and screwing. The package size is suitable for current projects and for on-site use.
This text is machine translated.
This text is machine translated.
Features
- Nominal diameter 3 mm
- Nominal length 30 mm
- Type 3x30
- Internal drive: HX10
- Contains 200 pieces
