SWG Hox 17901355015 Countersunk screws 3.5 mm 50 mm Star DIN 18360 Steel zinc plated 500 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
SWG Hox 17901355015 wood screw 3.5 x 50 mm HX10 drive
- The slim shaft profile allows controlled penetration for clean wood joints. The continuous sleeve length ensures uniform thread entry and secure fixing. The HX10 internal drive minimizes the risk of spinning when the engine is engaged or manually engaged. The delivery is made in large quantities for repeated assembly work without frequent refilling.
Technical specifications
- Product type
Countersunk screws
- Drive
Star
- Material
Steel
- Thread size
3.5 mm
- (Ø)
3.5 mm
- Length
50 mm
- Head shape
Countersunk
- Dim
(Ø x L) 3.5 mm x 50 mm
- DIN standard
DIN 18360
- Content
500 pc(s)
- Material properties
zinc plated
Documents & Downloads
Datasheet
Datasheet 3595231 SWG Hox 17901355015 Countersunk screws 3.5 mm 50 mm Star DIN 18360 Steel zinc plated 500 pc(s)
User & Safety Instructions
User & Safety Instructions 3595231 SWG Hox 17901355015 Countersunk screws 3.5 mm 50 mm Star DIN 18360 Steel zinc plated 500 pc(s)
Information
Test Summary Report 3595231 SWG Hox 17901355015 Countersunk screws 3.5 mm 50 mm Star DIN 18360 Steel zinc plated 500 pc(s)
Conformity certificate
Conformity certificate 3595231 SWG Hox 17901355015 Countersunk screws 3.5 mm 50 mm Star DIN 18360 Steel zinc plated 500 pc(s)
Description
This wood screw is used to fasten wooden components. It converts the torque via its threaded shaft into an axial clamping force. The installation is done with an HX10 screwdriver which transfers the torque to the screw and at the same time minimizes slipping. Thanks to its geometry, the screw fits deeply into the wood fibers and pulls the components together when screwed in. It is therefore suitable Ideal for recurring carpentry or installation work, in which a uniform hold and a reproducible mounting are needed. The packaging designed for commercial use enables smooth workflows and simple on-site storage.
This text is machine translated.
This text is machine translated.
Features
- Nominal diameter 3.5 mm
- Nominal length 50 mm
- Internal drive: HX10
- Contains 500 pieces
