SWG Hox 17901508063 Countersunk screws 5 mm 80 mm Star DIN 18360 Steel zinc plated 20 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
SWG Hox 17901508063 wood screw 5x80mm HX20 countersunk head
- The countersunk head construction enables flush turning in wood. The internal HX20 drive reduces the slipping out of the screw head during motorized or manual assembly and thus ensures a uniform fit. The long shaft simplifies the connection of thicker wooden sections or terrace areas. The pack size offers sufficient material for repeated assembly work.
Technical specifications
- Product type
Countersunk screws
- Drive
Star
- Material
Steel
- Thread size
5 mm
- (Ø)
5 mm
- Length
80 mm
- Head shape
Countersunk
- Dim
(Ø x L) 5 mm x 80 mm
- DIN standard
DIN 18360
- Content
20 pc(s)
- Material properties
zinc plated
Documents & Downloads
Datasheet
Datasheet 3595327 SWG Hox 17901508063 Countersunk screws 5 mm 80 mm Star DIN 18360 Steel zinc plated 20 pc(s)
User & Safety Instructions
User & Safety Instructions 3595327 SWG Hox 17901508063 Countersunk screws 5 mm 80 mm Star DIN 18360 Steel zinc plated 20 pc(s)
Information
Test Summary Report 3595327 SWG Hox 17901508063 Countersunk screws 5 mm 80 mm Star DIN 18360 Steel zinc plated 20 pc(s)
Conformity certificate
Conformity certificate 3595327 SWG Hox 17901508063 Countersunk screws 5 mm 80 mm Star DIN 18360 Steel zinc plated 20 pc(s)
Description
This wood screw is used for fixing wood components. It converts the torque into axial clamping force while the thread shaft is screwed into the wood. The internal HX20 drive is compatible with compatible bits for effective torque transfer when turning in the motor. The countersunk head ensures that the screw is flush with the wooden surface. Its length and thread penetration makes it suitable for continuous mounting and structural connections requiring longer screws. Typical applications are terrace construction and general carpentry work, where repeated, reliable installation and a clean finish are required.
This text is machine translated.
This text is machine translated.
Features
- Diameter: 5 mm
- Length 80 mm
- Drive type: HX20
- Head shape: Countersunk head
- Content: 20 pieces
