SWG Hox 17901510015 Countersunk screws 5 mm 100 mm Star DIN 18360 Steel zinc plated 100 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
SWG Hox 17901510015 wood screw 5x100mm HX20 straight shaft
- The nominal diameter of 5 mm provides high shear strength for the attachment of wooden components. The nominal length of 100 mm allows deep penetration for secure connections even with thicker wood cross-sections. The HX20 Allen Drive reduces spin and facilitates torque transfer during motor-driven assembly work. The delivery takes place in a 100-pack, WAS simplifies the handling of large projects and reduces re-orders.
Technical specifications
- Product type
Countersunk screws
- Drive
Star
- Material
Steel
- Thread size
5 mm
- (Ø)
5 mm
- Length
100 mm
- Head shape
Countersunk
- Dim
(Ø x L) 5 mm x 100 mm
- DIN standard
DIN 18360
- Content
100 pc(s)
- Material properties
zinc plated
Documents & Downloads
Datasheet
Datasheet 3595293 SWG Hox 17901510015 Countersunk screws 5 mm 100 mm Star DIN 18360 Steel zinc plated 100 pc(s)
User & Safety Instructions
User & Safety Instructions 3595293 SWG Hox 17901510015 Countersunk screws 5 mm 100 mm Star DIN 18360 Steel zinc plated 100 pc(s)
Information
Test Summary Report 3595293 SWG Hox 17901510015 Countersunk screws 5 mm 100 mm Star DIN 18360 Steel zinc plated 100 pc(s)
Conformity certificate
Conformity certificate 3595293 SWG Hox 17901510015 Countersunk screws 5 mm 100 mm Star DIN 18360 Steel zinc plated 100 pc(s)
Description
This wood screw is a fastening element for joining wood elements. It converts the torque into pulling force and engages in the thread. Installation is performed using an Allen key screwdriver (HX20), which transfers the torque directly to the screw and pulls the shaft into the wood while the thread cuts or shapes. Thanks to their length, the screw is suitable for thicker boards or stable overleaf. The nominal diameter contributes to the load capacity for shear and tensile strength. The screws are supplied in large quantities and are intended for repeated or larger assembly operations requiring smooth intervention and reliable penetration.
This text is machine translated.
This text is machine translated.
Features
- Nominal diameter 5 mm
- Nominal length 100 mm
- Internal drive: HX20
- Content: 100 pieces
- Type 5 x 100
