SWG Hox 17901604063 Countersunk screws 6 mm 40 mm Star DIN 18360 Steel zinc plated 25 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
SWG Hox 17901604063 wood screw 6x40mm HX30 internal drive
- Cylindrical shaft geometry provides a secure grip in the wood on carrying joints. The internal HX30 drive minimizes slip during manual or manual assembly and ensures uniform torque transmission. The nominal diameter of 6 mm allows compatibility with pre-drilled pilot holes for controlled insertion. The delivery takes place in a 25-pack for serial mounting and a simple storage.
Technical specifications
- Product type
Countersunk screws
- Drive
Star
- Material
Steel
- Thread size
6 mm
- (Ø)
6 mm
- Length
40 mm
- Head shape
Countersunk
- Dim
(Ø x L) 6 mm x 40 mm
- DIN standard
DIN 18360
- Content
25 pc(s)
- Material properties
zinc plated
Documents & Downloads
Datasheet
Datasheet 3595363 SWG Hox 17901604063 Countersunk screws 6 mm 40 mm Star DIN 18360 Steel zinc plated 25 pc(s)
User & Safety Instructions
User & Safety Instructions 3595363 SWG Hox 17901604063 Countersunk screws 6 mm 40 mm Star DIN 18360 Steel zinc plated 25 pc(s)
Information
Test Summary Report 3595363 SWG Hox 17901604063 Countersunk screws 6 mm 40 mm Star DIN 18360 Steel zinc plated 25 pc(s)
Conformity certificate
Conformity certificate 3595363 SWG Hox 17901604063 Countersunk screws 6 mm 40 mm Star DIN 18360 Steel zinc plated 25 pc(s)
Description
This wood screw is used to fasten wooden components. When screwed in, it cuts and displaces the wood fibers and thus forms a secure mechanical joint. The internal HX30 drive is compatible with matching bits and efficiently transmits torque while minimizing overturning. A suitable screwdriver is normally used for installation. If necessary, a pilot hole is drilled, the diameter of which corresponds to the diameter of the screw to check the fitting and to prevent the wood from splitting. The bolt geometry creates a clamping force between the connected parts and thus makes the screw Ideal for repeated assembly and general carpentry work where uniform turning behavior is required.
This text is machine translated.
This text is machine translated.
Features
- Nominal diameter 6 mm
- Nominal length 40 mm
- Type 6 x 40
- Internal drive: HX30
- Content: 25 pieces
