SWG Hox 17901605067 Countersunk screws 6 mm 50 mm Star DIN 18360 Steel zinc plated 75 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
SWG Hox 17901605067 wood screw 6x50mm HX30 countersunk head
- The nominal diameter of 6 mm ensures compatibility with metric pilot holes for wood joints and thus ensures a precise fit during assembly. The 50 mm nominal length makes possible a safe penetration in standard wood profiles and improves the connection strength without continuous screwing. The internal HX30 drive reduces the risk of slipping out during machine assembly and ensures uniform torque transmission. The delivery takes place in a 75 pack to facilitate recurring assembly work and to reduce reordering frequency on site.
Technical specifications
- Product type
Countersunk screws
- Drive
Star
- Material
Steel
- Thread size
6 mm
- (Ø)
6 mm
- Length
50 mm
- Head shape
Countersunk
- Dim
(Ø x L) 6 mm x 50 mm
- DIN standard
DIN 18360
- Content
75 pc(s)
- Material properties
zinc plated
Documents & Downloads
Datasheet
Datasheet 3595370 SWG Hox 17901605067 Countersunk screws 6 mm 50 mm Star DIN 18360 Steel zinc plated 75 pc(s)
User & Safety Instructions
User & Safety Instructions 3595370 SWG Hox 17901605067 Countersunk screws 6 mm 50 mm Star DIN 18360 Steel zinc plated 75 pc(s)
Conformity certificate
Conformity certificate 3595370 SWG Hox 17901605067 Countersunk screws 6 mm 50 mm Star DIN 18360 Steel zinc plated 75 pc(s)
Description
This wood screw is a mounting element for connecting wooden components using an Allen drive. It works by pressing the thread shaft into the wood fibers when turning the screw, tightening the parts and converting the applied torque into an axial clamping force. The countersunk head ensures that the screw is flush with the surface after screwing in, WAS ensures a clean finish and prevents jamming of neighboring parts. A suitable HX30 bit is usually used for installation in a cordless screwdriver or hand tool. This allows controlled turning in and a sufficient contact surface on the work piece for common wood working and assembly work.
This text is machine translated.
This text is machine translated.
Features
- Nominal diameter 6 mm
- Nominal length 50 mm
- Internal drive: HX30
- Type name: 6x50
- Contains 75 pieces
