SWG Hox 17901608067 Countersunk screws 6 mm 80 mm Star DIN 18360 Steel zinc plated 50 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
SWG Hox 17901608067 wood screw 6x80mm HX30 countersunk head
- The nominal diameter of 6 mm ensures a stable drilling of wood joints and improves the load distribution during screwing. The nominal length of 80 mm allows you to penetrate common wood cross-sections for secure connections in steel construction. The HX30 internal drive reduces overturning when using cordless screwdrivers and thus contributes to an efficient mounting. Supplied in a pack of 50 to allow repeated fixings without frequent refilling.
Technical specifications
- Product type
Countersunk screws
- Drive
Star
- Material
Steel
- Thread size
6 mm
- (Ø)
6 mm
- Length
80 mm
- Head shape
Countersunk
- Dim
(Ø x L) 6 mm x 80 mm
- DIN standard
DIN 18360
- Content
50 pc(s)
- Material properties
zinc plated
Documents & Downloads
Datasheet
Datasheet 3595382 SWG Hox 17901608067 Countersunk screws 6 mm 80 mm Star DIN 18360 Steel zinc plated 50 pc(s)
User & Safety Instructions
User & Safety Instructions 3595382 SWG Hox 17901608067 Countersunk screws 6 mm 80 mm Star DIN 18360 Steel zinc plated 50 pc(s)
Information
Test Summary Report 3595382 SWG Hox 17901608067 Countersunk screws 6 mm 80 mm Star DIN 18360 Steel zinc plated 50 pc(s)
Conformity certificate
Conformity certificate 3595382 SWG Hox 17901608067 Countersunk screws 6 mm 80 mm Star DIN 18360 Steel zinc plated 50 pc(s)
Description
This wood screw is used to fasten wood by converting the torque of the screwdriver into axial penetration and thread penetration in the wood fibers. The internal HX30 drive is compatible with compatible bits for mechanical or manual assembly. The bolt geometry pulls the adjacent wooden elements together when turning them in. Typical applications are bar joints, terrace coverings and general wood fittings where a medium long fastening element is required. The package size is Ideal for projects with several identical fasteners. The screw is suitable for use wherever 6 mm diameter and a medium length wood fixing element are required.
This text is machine translated.
This text is machine translated.
Features
- Nominal diameter 6 mm
- Nominal length 80 mm
- Internal drive: HX30
- Contains 50 pieces
