SWG Hox 17901611063 Countersunk screws 6 mm 110 mm Star DIN 18360 Steel zinc plated 20 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
SWG Hox 17901611063 wood screw 6x110 mm HX30 countersunk head
- The nominal diameter of 6 mm ensures a secure hold in wood for load-carrying connections. The nominal length of 110 mm allows deeper fastenings for supporting structures. The HX30 Allen Drive reduces overturning and allows controlled torque with hexagon screwdrivers. The delivery takes place in 20-pack for practical quantities on site and less re-orders.
Technical specifications
- Product type
Countersunk screws
- Drive
Star
- Material
Steel
- Thread size
6 mm
- (Ø)
6 mm
- Length
110 mm
- Head shape
Countersunk
- Dim
(Ø x L) 6 mm x 110 mm
- DIN standard
DIN 18360
- Content
20 pc(s)
- Material properties
zinc plated
Documents & Downloads
Datasheet
Datasheet 3595338 SWG Hox 17901611063 Countersunk screws 6 mm 110 mm Star DIN 18360 Steel zinc plated 20 pc(s)
User & Safety Instructions
User & Safety Instructions 3595338 SWG Hox 17901611063 Countersunk screws 6 mm 110 mm Star DIN 18360 Steel zinc plated 20 pc(s)
Information
Test Summary Report 3595338 SWG Hox 17901611063 Countersunk screws 6 mm 110 mm Star DIN 18360 Steel zinc plated 20 pc(s)
Conformity certificate
Conformity certificate 3595338 SWG Hox 17901611063 Countersunk screws 6 mm 110 mm Star DIN 18360 Steel zinc plated 20 pc(s)
Description
This wood screw is used for fixing wood components. It converts the torque via its threaded shaft into axial draft resistance. The Allen drive allows you to use HX30 hex screwdriver for efficient torque transfer and proper screwdriver alignment. The long shaft allows the penetration into thicker components or several elements and thus guarantees safe mechanical connections, even at deep anchoring depth. The screws are supplied in a pack size suitable for small to medium-sized assembly work. They are typically used where a counter-sunk head is needed for flush-fitting screwdriving in wood construction or wood construction.
This text is machine translated.
This text is machine translated.
Features
- Diameter 6 mm
- Length: 110 mm
- HX30 hex socket drive
- Quantity: 20 pieces
- Type name: 6x110
