SWG Hox 17901611067 Countersunk screws 6 mm 110 mm Star DIN 18360 Steel zinc plated 50 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
SWG Hox 17901611067 wood screw 6x110mm HX30 head
- The long stem length provides deep intervention in heavy wood joints and thus improves the stability.
- The nominal diameter of 6 mm provides high shear strength for load-bearing connections during assembly.
- The internal HX30 drive reduces slip during motorized assembly and allows for more even torque transmission. Supplied in a pack of 50 to facilitate repeated assembly and reduce component replacement.
Technical specifications
- Product type
Countersunk screws
- Drive
Star
- Material
Steel
- Thread size
6 mm
- (Ø)
6 mm
- Length
110 mm
- Head shape
Countersunk
- Dim
(Ø x L) 6 mm x 110 mm
- DIN standard
DIN 18360
- Content
50 pc(s)
- Material properties
zinc plated
Documents & Downloads
Datasheet
Datasheet 3595339 SWG Hox 17901611067 Countersunk screws 6 mm 110 mm Star DIN 18360 Steel zinc plated 50 pc(s)
User & Safety Instructions
User & Safety Instructions 3595339 SWG Hox 17901611067 Countersunk screws 6 mm 110 mm Star DIN 18360 Steel zinc plated 50 pc(s)
Information
Test Summary Report 3595339 SWG Hox 17901611067 Countersunk screws 6 mm 110 mm Star DIN 18360 Steel zinc plated 50 pc(s)
Conformity certificate
Conformity certificate 3595339 SWG Hox 17901611067 Countersunk screws 6 mm 110 mm Star DIN 18360 Steel zinc plated 50 pc(s)
Description
This wood screw is a fastening element for connecting wooden components. It converts rotary assembly into axial penetration and thread penetration. The assembly is carried out by screwing in the screw with a compatible HX30 bit. This bit engages in the internal drive, transmits the torque and drives the screw into the wood. The geometry of the thread and shaft produces a radial compression of the wood fibers and thus forms a fixed connection, which is suitable for construction and table work. The bolts are supplied in a multi-piece package and are designed for repeated assembly operations requiring uniform thread engagement and deep anchorage.
This text is machine translated.
This text is machine translated.
Features
- Nominal diameter 6 mm
- Nominal length 110 mm
- Type name: 6x110
- Internal drive: HX30
- Contains 50 pieces
