SWG Hox 17901616015 Countersunk screws 6 mm 160 mm Star DIN 18360 Steel zinc plated 100 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
SWG Hox 17901616015 wood screw 6x160mm HX30 hex socket
- The nominal diameter of 6 mm provides for a firm grip in the wood and thus for a secure attachment. The nominal length of 160 mm allows the penetration into deep joints in load-bearing wooden structures. The internal HX30 drive allows mounting with matching Allen keys for a controlled torque. Supplied in a pack of 100 units, Ideal for series or multiple mounting.
Technical specifications
- Product type
Countersunk screws
- Drive
Star
- Material
Steel
- Thread size
6 mm
- (Ø)
6 mm
- Length
160 mm
- Head shape
Countersunk
- Dim
(Ø x L) 6 mm x 160 mm
- DIN standard
DIN 18360
- Content
100 pc(s)
- Material properties
zinc plated
Documents & Downloads
Datasheet
Datasheet 3595350 SWG Hox 17901616015 Countersunk screws 6 mm 160 mm Star DIN 18360 Steel zinc plated 100 pc(s)
User & Safety Instructions
User & Safety Instructions 3595350 SWG Hox 17901616015 Countersunk screws 6 mm 160 mm Star DIN 18360 Steel zinc plated 100 pc(s)
Information
Test Summary Report 3595350 SWG Hox 17901616015 Countersunk screws 6 mm 160 mm Star DIN 18360 Steel zinc plated 100 pc(s)
Conformity certificate
Conformity certificate 3595350 SWG Hox 17901616015 Countersunk screws 6 mm 160 mm Star DIN 18360 Steel zinc plated 100 pc(s)
Description
This wood screw is used for connecting wooden components. It converts the torque into axial traction force while the thread shaft is screwed into the wood. The hexagonal socket (HX30) takes a suitable screwdriver to transfer the torque and at the same time minimize the slipping when screwing in the machine. Thanks to its considerable length, it enables the penetration of thicker materials or several layers and thus the effective fixing of components. The screws are supplied in a multi-part package and are suitable for repeated assembly work in construction and in the carpentry, where a uniform drive interface and uniform dimensions simplify assembly and maintenance.
This text is machine translated.
This text is machine translated.
Features
- Nominal diameter 6 mm
- Nominal length 160 mm
- Internal drive: HX30
- Content: 100 pieces
- Type 6 x 160
