SWG Hox 17901620015 Countersunk screws 6 mm 200 mm Star DIN 18360 Steel zinc plated 50 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
SWG Hox 17901620015 wood screw 6x200mm HX30
- The long shaft design allows deep penetration for secure wood joints. The thread profile offers high tensile strength for the structural mounting. The internal HX30 drive reduces slipping during machine assembly. Delivery in 50-Pack for serial mounting and repetitive applications
Technical specifications
- Product type
Countersunk screws
- Drive
Star
- Material
Steel
- Thread size
6 mm
- (Ø)
6 mm
- Length
200 mm
- Head shape
Countersunk
- Dim
(Ø x L) 6 mm x 200 mm
- DIN standard
DIN 18360
- Content
50 pc(s)
- Material properties
zinc plated
Documents & Downloads
Datasheet
Datasheet 3595354 SWG Hox 17901620015 Countersunk screws 6 mm 200 mm Star DIN 18360 Steel zinc plated 50 pc(s)
User & Safety Instructions
User & Safety Instructions 3595354 SWG Hox 17901620015 Countersunk screws 6 mm 200 mm Star DIN 18360 Steel zinc plated 50 pc(s)
Information
Test Summary Report 3595354 SWG Hox 17901620015 Countersunk screws 6 mm 200 mm Star DIN 18360 Steel zinc plated 50 pc(s)
Conformity certificate
Conformity certificate 3595354 SWG Hox 17901620015 Countersunk screws 6 mm 200 mm Star DIN 18360 Steel zinc plated 50 pc(s)
Description
This wood screw is a mounting element for wood joints with a long range. It transfers torque to the screw body via an internal HX30 drive, allowing installers to use compatible screwdrivers for controlled turning. The screw is pushed through its external thread, pulls the work pieces together and creates a clamping effect through the threaded penetration in the wood fibers. Its length is suitable for applications requiring thick material thicknesses or multiple layers to penetrate, and the pack size is suitable for repeated assembly work on site or in the workshop.
This text is machine translated.
This text is machine translated.
Features
- Nominal diameter 6 mm
- Nominal length 200 mm
- Internal drive: HX30
- Type 6 x 200
- Contains 50 pieces
