Theben KNX 2069650 Motion detector Max. range (open field) 17 m theMura S180 KNX UP WH
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Product type
Motion detector
- Series
KNX
- Used at
Indoors
- Data transfer (Smart Home)
Wired
- Channels
2
17 m
- Mounting type
Flush mount
- Width
85 mm
- Height
85 mm
- Depth
44 mm
- (Ø)
17 m
- Dim
(Ø x H) 17 m x 85 mm
- Hub
Not required, optional for remote access
- Weight
0.014 kg
- Features
Dimmer function
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3358207 Theben KNX 2069650 Motion detector Max. range (open field) 17 m theMura S180 KNX UP WH
User & Safety Instructions
User & Safety Instructions 3358207 Theben KNX 2069650 Motion detector Max. range (open field) 17 m theMura S180 KNX UP WH
User & Safety Instructions 3358207 Theben KNX 2069650 Motion detector Max. range (open field) 17 m theMura S180 KNX UP WH
Description
KNX passive infrared motion detector for wall mounting, 1-channel light and 1-channel HVAC, KNX Data-Secure, with Theben cover frame, cover frame for integration in standard switch programs available as accessories, rectangular coverage range from 170° to 14x17 m, automatic presence and brightness-dependent control for lighting, switching or dimmable lighting in switching mode with and without daylight, 3 logic channels (and, OR, XOR), operation as automatic or semi-automatic, switchable, brightness switching value adjustable, teach-in function, delay time and follow-up time adjustable, possible restriction of the detection range, integrated button can be freely parameterized (blocked), extension of the detection area by Master/slave switching
