Theben KNX 4940275 Dimmer actuator DM 4 T KNX
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Lamp types Incandescent lamps, low voltage and high-voltage halogen lamps, dimmable compact fluorescent lamps and LED
- Switching capacity per channel: 400 W
- Switching capacity in parallel operation: 800 W
- LED-Lamp: phase section (RC-mode): 400 W
- Compact fluorescent lamps: phase section (RC-mode): 400 W
- Switching power min: 5 W
- Max. Cable length: 100 m
- Ambient temperature: -5°C ... 45°C
- Product type
Dimmer actuator
- Series
KNX
- Max. switching capacity
1600 W
- Used at
Indoors
IP20
- Operating voltage
230 V AC
400 W
- Data transfer (Smart Home)
Wired
- Channels
4
- Mounting type
DIN rail
- Factory colour
Multicolour
- Hub
Not required, optional for remote access
n.rel.
- Features
Dimmer function
DRA (DIN-rail adapter)
Dimming actuator
50-50 MHz
TRUE
FALSE
FALSE
TRUE
8
FALSE
IP20
TRUE
FALSE
FALSE
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2157624 Theben KNX 4940275 Dimmer actuator DM 4 T KNX
User & Safety Instructions
User & Safety Instructions 2157624 Theben KNX 4940275 Dimmer actuator DM 4 T KNX
Description
KNX universal dimming actuator 4-way, mounting enclosure, width 8 TE, dimming range 0-100%, maximum load: 4 x 400 W/VA or 1 x 1600 W/VA, when using the channels as a control output up to 5 DIMM booster DMB1T with max. 5 x 400 W/VA power per channel can be controlled. For dimming the light bulbs, low-voltage and high-voltage halogen lamps, dimmable energy saving lamps, dimmable LED retrofit lamps. Different Dimm curves allow a stepless dimming of all lamp types, also suitable for controlling many fans, automatic load detection (selectable), manual operation 0, 25, 50, 75 and 100% or test
