Turck Sensor Inductive shielded PNP NO BID2-G180-AP6-H1141/S212

Technical drawing of a cylindrical part with dimensions: ø15, M18x1, M12x1. O-ring label. Contains thread turns and specific dimensions.
Technical drawing of a cylindrical connector with M12 thread. Dimensions and O-ring position are shown on the right.
1/2
Product type
Sensor
Max. operating voltage
30 V
Outputs
PNP NO
Switching distance (max.)
2 mm
Model
Inductive
Datasheet (PDF)
EAN:
Part number:
Item no:
Unavailable
Sales and shipping:
Conrad ElectronicTerms & Conditions
Report legal concerns

Technical specifications

Product type

Sensor

Type

BID2-G180-AP6-H1141/S212

Min. operating voltage

10 V

Max. operating voltage

30 V

Operating voltage

10 - 30 V

Outputs

PNP NO

Switching distance (max.)

2 mm

Switching frequency

2000 Hz

Model

Inductive

Connector

Terminal

Installation type

shielded

Enclosure material

Metal

Length

58 mm

(Ø)

18 mm

Dim

(Ø x L) 18 mm x 58 mm

DC

Metal

FALSE

2000 Hz

2 mm

Plug-in connection

PNP

Normally open contact

Cylinder, screw-thread

Concise

10-30 V

Metallic Target

18 mm

58 mm

UKCA

yes

Documents & Downloads

Datasheet

Datasheet 2832410 Turck Sensor Inductive shielded PNP NO BID2-G180-AP6-H1141/S212

User & Safety Instructions

User & Safety Instructions 2832410 Turck Sensor Inductive shielded PNP NO BID2-G180-AP6-H1141/S212
