Buy Vogt Verbindungstechnik 3801.60 Blade receptacle Connector width: 4.8 mm Connector thickness: 0.8 mm 180 ° Not insulated

A brass plug in close-up, with two parallel cavities and a curved shape for electrical connections.

Technical drawing of a connector with dimensions L1, L2, L3, S, A1, A2. Side view and front view depicted.

1/2

Image similar

Datasheet (PDF)

5242 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Quantity (Piece(s))

Savings

Package size (plus VAT.)

Volume discounts vary depending on the seller

You save € 0.00

Number

Piece(s)

Minimum order quantity: 30

Total (€ 0.08 / piece)

€ 0.15

-47 %

€

Report legal concerns

Highlights & Details

Vogt Verbindungstechnik 3801.60 Blade receptacle Connector width: 4.8 mm Connector thickness: 0.8 mm 180 ° Not insulated Metal 1 pc(s)

DIN 46247/1

Technical specifications

Factory colour: Metal

Contact material: Brass

Content: 1 pc(s)

Dim

Cross-section range: 0.50 - 1 mm²

Size: 4.8 x 0.8 mm

Insulation type: Not insulated

Manufacturer part #: 3801.60

Type: 3801.60

Material (details): Polished brass

Type: 4.8 x 0.8 mm

AWG max.: 18

AWG (min.): 22

max. cross section: 1 mm²

Connector thickness: 0.8 mm

Connector width: 4.8 mm

Connection angle: 180°

Cross section: 0.5 - 1.0 mm²

Connection: -

Min. cross section: 0.50 mm²

Support sleeve: No

Product type: Blade receptacle
