VOLTCRAFT VC-510 Clamp meter adapter Calibrated to (SCS-accredited certification body)
EAN:
Part number:
Item no:
Highlights & Details
AC clip-on ammeter adapter VC-510 - SCS calibrated
- Current measurement up to 400 A/AC
- Integrated contact-free voltage tester
- Opening angle 30 mm
Our service for you
Technical specifications
- Opening range of current clamps
30 mm
- Product type
Clamp meter adapter
- Type B
4 mm jack
SCS-accredited certification body
- Amperage reading range AC (max.)
400 A
- Basic accuracy
±2.5 %
- Dim
(L x W x H) 149 x 63 x 37 mm
- Current reading
AC
- Reading category
CAT III 600 V
CAT IV 300 V
- Weight
220 g
- Calibration service
10 calibration values per range; DC, AC
- Width
63 mm
- Height
37 mm
- Length
149 mm
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2470710 VOLTCRAFT VC-510 Clamp meter adapter Calibrated to (SCS-accredited certification body)
Warranty Terms
Warranty Terms 2470710 VOLTCRAFT VC-510 Clamp meter adapter Calibrated to (SCS-accredited certification body)
Description
You can now measure AC currents up to 400 A contactless with your digital multimeter, without disconnecting wires. simply attach the adapter of clip-on ammeter via the 4 mm of banana plug to a multimeter oscilloscope or the like. The output of the clip-on ammeter adapter takes place in mV/A. The device is very sturdy by the soft rubber protection and is additionally equipped with a contactless voltage tester
This text is machine translated.
This text is machine translated.
Scope of delivery
- Batteries (type AAA)
- User manual.
Hints
Please note the sample calibration certificate stored under "Downloads" for the scope of the calibration.
Your right to cancel does not apply to this product.
Accessories
(*All information is plus legal VAT)The necessary accessories are required to use the article as described.
