Name: W-Series, Feed-through terminal, Rated cross-section: 1,5 mm², Screw connection, Direct mounting
Brand: Weidmüller
SKU: 281392

Plastic clamping rail with two screw connections, side mounting brackets, and symmetrical design.

Packaging type

Piece

Product type

Serial continuity

Connection

Screws

Cross section (flexible) (max.)

1.5 mm²

Cross section (inflexible) (max.)

2.5 mm²

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Highlights & Details

W-Series, Feed-through terminal, Rated cross-section: 1,5 mm², Screw connection, Direct mounting

WDU 1.5/ZZ BL

Our service for you

Technical specifications

Packaging type: Piece

Product type: Serial continuity

Features: with screw connection

Connection: Screws

Cross section (flexible) (min.): 0.5 mm²

Cross section (flexible) (max.): 1.5 mm²

Cross section (inflexible) (min.): 0.5 mm²

Cross section (inflexible) (max.): 2.5 mm²

Factory colour: Blue

Manufacturer part #: 1031480000

Content: 100 pc(s)

Industrial packaging: Yes

Type: WDU 1.5/ZZ BL

Dim: (L x W x H) 60 x 5.1 x 46.5 mm

Width: 5.1 mm

Height: 46.5 mm

Length: 60 mm

RoHS-compliant: Yes

Weight: 8.1 g

Connector colour: Blue

Type: WDU 1.5/ZZ BL

: DIN rail (top hat rail) 35 mm

: Blue

: 5.1

: 60 mm

: 46.5 mm

: 800 V

: -60-130 °C

: V0

: TRUE

: Screw connection

: Screw connection

: 1

: 4

: FALSE

: 0.5-2.5 mm²

: 0.5-1.5 mm²

: 0.5-1.5 mm²

: 0.5-2.5 mm²

: Thermoplastic

: 17.5 A

: TRUE

UKCA: not relevant

Documents & Downloads

Datasheet

Datasheet 281392 W-Series, Feed-through terminal, Rated cross-section: 1,5 mm², Screw connection, Direct mounting

User & Safety Instructions

User & Safety Instructions 281392 W-Series, Feed-through terminal, Rated cross-section: 1,5 mm², Screw connection, Direct mounting

Description

The versatile and extensive range of products - from 0.05 mm² to 300 mm² - means that you have diverse options for your applications at your disposal.
Hardened steel for mechanical strength and high-quality tinned copper for optimum conductivity. All materials comply with RoHS requirements and have been tested to current environment guidelines.
