W-Series, PE terminal, Rated cross-section: 35 mm², Screw connection, Direct mounting
EAN:
Part number:
Item no:
Product type
Earth clamp
Connection
Screws
Cross section (flexible) (max.)
35 mm²
Cross section (inflexible) (max.)
16 mm²
Content
25 pc(s)
Datasheet (PDF)
Highlights & Details
W-Series, PE terminal, Rated cross-section: 35 mm², Screw connection, Direct mounting
- WPE 35/IKSC
Technical specifications
- Product type
Earth clamp
- Features
with screw connection
- Connection
Screws
- Cross section (flexible) (min.)
2.5 mm²
- Cross section (flexible) (max.)
35 mm²
- Cross section (inflexible) (min.)
2.5 mm²
- Cross section (inflexible) (max.)
16 mm²
- Factory colour
Green-yellow
- Manufacturer part #
1012600000
- Content
25 pc(s)
- Industrial packaging
Yes
- Type
WPE 35/IKSC
- Dim
(L x W x H) 56 x 16 x 62.5 mm
- Width
16 mm
- Height
62.5 mm
- Length
56 mm
- RoHS-compliant
Yes
- Weight
81.36 g
- Connector colour
Green-yellow
- Type
WPE35/IKSC
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 280362 W-Series, PE terminal, Rated cross-section: 35 mm², Screw connection, Direct mounting
User & Safety Instructions
User & Safety Instructions 280362 W-Series, PE terminal, Rated cross-section: 35 mm², Screw connection, Direct mounting
Description
Earthing terminal. W-series, rated cross-section: 35 mm², screw connection, direct mounting.
