Weidmüller 1063930000 VSSC4 SL FG 24VAC/DC Ex Surge arrester 10 kA 1 pc(s)
EAN:
Part number:
Item no:
Technical specifications
- Net weight: 39.6 g
- Humidity: 5...96%
- Storage temperature: -40 °C to +80 °C.
- Design: Clamp
- Flammability class V-0
- Number of poles: 1
- Pollution level: 2
- Over voltage category III
- Connection type: screw terminals.
- Segment: Measure - Control - Rules
- Mounting rail TS 35
- Maximum continuous voltage, UC (AC) 30 V.
- Protection level UP (typ.) 150 V
- Tightening torque, min.: 0.5 Nm
- Tightening torque, max.: 0.8 Nm
- Clamping range, min. 0.5 mm²
- Clamping range, max. 4 mm²
- Conductor cross-section, single-wire, min. 0.5 mm²
- Conductor cross-section, single-wire, max. 6 mm²
- Conductor cross-section, multi-strand, min.: 0.5 mm²
- Conductor cross-section, multi-strand, max. 4 mm²
- Insertion loss 5.24 MHz
- Nominal current IN: 300 mA
- Maximum continuous voltage, UC (DC) 42 V.
- Forward resistance 1.8 Ω 10 %
- Product type
Surge arrester
- Leakage current
10 kA
- Nominal voltage
24 V AC
- Operating temperature
-40 °C to +70 °C °C
IP20
- Manufacturer part #
1063930000
- Type
VSSC4 SL FG 24VAC/DC EX
- Factory colour
Light blue
- Dim
(W x H x D) 12.4 x 76 x 58.5 mm
- Width
12.4 mm
- Height
76 mm
- Depth
58.5 mm
- RoHS-compliant
Yes
- Content
1 pc(s)
- UKCA
yes
