Weidmüller 1226280000 Screw terminal 16 mm² Number of pins 10 Black 1 pc(s)
EAN:
Part number:
Item no:
Product type
Screw terminal
CS
10.16 mm
Pins per row
10
Number of pins
10
Connection
Print
Screw terminal
Datasheet (PDF)
Technical specifications
- Type
LU 10.16/10/90 4.5SN BK BX
- Product type
Screw terminal
- CS
10.16 mm
- No. of rows
1
- Pins per row
10
- Number of pins
10
- Series
LU
- Min. stripping length
12 mm
- Stripping length (max.)
12 mm
- Connection
Print
Screw terminal
- Nominal current
65 A
- Cross section (flexible) (min.)
0.5 mm²
- Nominal current - rounded value
65 A
- Cross section (inflexible) (min.)
0.5 mm²
- Cross section (flexible) (max.)
16 mm²
- Cross section (inflexible) (max.)
16 mm²
- AWG (min.)
22
- Connector orientation
Parallel (to the PCB)
- AWG max.
8
- Contact material
Cathode copper, tin plated
- Factory colour
Black
- Wire protection
Yes
- Actuation direction
Perpendicular (to the PCB)
- Weight
96.5 g
- Manufacturer part #
1226280000
- Industrial packaging
Yes
- Content
1 pc(s)
- Nominal voltage
300 V
- Width
101.6 mm
- Height
33 mm
- Length
18.3 mm
- Type
LU 10.16/10/90 4.5SN BK BX
- UKCA
yes
