Weidmüller 1247290000 Serial test terminal 5.1 mm Screws Dark beige 50 pc(s)
EAN:
Part number:
Item no:
Product type
Serial test terminal
Connection
Screws
Cross section (flexible) (max.)
4 mm²
Cross section (inflexible) (max.)
4 mm²
Content
50 pc(s)
Datasheet (PDF)
Highlights & Details
Checks racing series terminal
- WDK 2.5/TR-DU
Our service for you
Technical specifications
- Product type
Serial test terminal
- Features
+ separator
- Connection
Screws
- Cross section (flexible) (min.)
0.5 mm²
- Cross section (flexible) (max.)
4 mm²
- Cross section (inflexible) (min.)
0.5 mm²
- Cross section (inflexible) (max.)
4 mm²
- Clamp width
5.1 mm
- No. of rows
2
- Factory colour
Dark beige
- Manufacturer part #
1247290000
- Content
50 pc(s)
- Industrial packaging
Yes
- Type
WDK 2.5/TR-DU
- Dim
(L x W x H) 80.5 x 5.1 x 66 mm
- Width
5.1 mm
- Height
66 mm
- Length
80.5 mm
- RoHS-compliant
Yes
- Weight
15.18 g
- Connector colour
Dark beige
- Type
WDK 2.5/TR-DU
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 320438 Weidmüller 1247290000 Serial test terminal 5.1 mm Screws Dark beige 50 pc(s)
User & Safety Instructions
User & Safety Instructions 320438 Weidmüller 1247290000 Serial test terminal 5.1 mm Screws Dark beige 50 pc(s)
Description
Checks racing series terminal. With the new wdk 2.5 YOU PE TR series can signal circuits space-saving with only one series terminal wired. While the signal via the upper level of the terminal block can be fed, offers the lower connection level space for the neutral conductor. In addition, your shield connection space saving with the integrated PE connection can be connected, what additional PE terminals or other terminal facilities in the control cabinet superfluous. Depending on the signal and requirements, the upper terminal level with a lever or with a pluggable safety lever SIHA. With only 5.1 mm width offers the wdk 2.5 YOU PE TR so far highest wiring density under all screw terminal blocks for the routing of signals. Without high flexibility and functionality to compromise.
This text is machine translated.
This text is machine translated.
What kind of Serial Terminals are you looking for?
Accessories
(*All information is plus legal VAT)The necessary accessories are required to use the article as described.
