Weidmüller 1288820300 Sensor/actuator data cable (pre-fab) M12 Plug, straight 3.00 m No. of pins (RJ): 4 1 pc(s)
EAN:
Part number:
Item no:
Product type
Sensor/actuator data cable (pre-fab)
Connector type
Plug, straight
Connection side A
M12 plug, straight
Connection side B
USB connector
No. of pins
4
Technical specifications
- Housing base material: PUR
- Insulation resistance: 108 Ω
- Temperature range Housing: -25 °C - +80 °C
- Insulation: PE
- Color coding: White, green, red, black
- configurable cable length: No
- Material threaded ring: Brass, nickel-plated
- Tightening torque: M12: 0.8 Nm - 1.2 Nm
- Type
SAIL-M12BG-USB-3.0U
- Product type
Sensor/actuator data cable (pre-fab)
- Connector type
Plug, straight
- Connection side A
M12 plug, straight
- Connection side B
USB connector
- No. of pins
4
- Cable length
3.00 m
- Jacket material
PUR
- Nominal voltage
5 V
- Nominal current
1 A
- Nominal current - rounded value
1 A
- Factory colour
Black
- Thread type connection side
M12
- Cable colour
Black
- Coding
A
- Contact surface
Gold plated
IP67
- Features
Halogen-free
Shielded
- Manufacturer part #
1288820300
- Content
1 pc(s)
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2242161 Weidmüller 1288820300 Sensor/actuator data cable (pre-fab) M12 Plug, straight 3.00 m No. of pins (RJ): 4 1 pc(s)
