Weidmüller 1349950010 PAC-UNIV-D9M-D9F-1M PLC cable
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
Plc Cable
- PAC UNIV-D9M-D9F-1M
Technical specifications
- Storage temperature, max.: 60 °C
- Storage temperature, min.: -10 °C
- Connection interface: SUB-D MALE 9P
- Connection SPS: SUB-D FEMALE 9P
- Outer diameter: 7.8 ± 1 mm
- Cable: LiYCY
- Wire cross-section: 0.25 mm²
- Nominal voltage: ≤ 60 Vdc ≤ 25 Vac
- Permissible current per path, max.: 1 A
- Total current, max.: 3 A
- Resistance: ≤ 80 mΩ/m.
- Product type
PLC cable
- Manufacturer part #
1349950010
- Type
PAC-UNIV-D9M-D9F-1M
- Cable length
1.00 m
- Material
PVC
- Number of pins
9
- Max. temperature
+50 °C
- Min. temperature
-10 °C
- Weight
191 g
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 202739 Weidmüller 1349950010 PAC-UNIV-D9M-D9F-1M PLC cable
User & Safety Instructions
User & Safety Instructions 202739 Weidmüller 1349950010 PAC-UNIV-D9M-D9F-1M PLC cable
Description
Plc cable. The pre-assembled PAC-cable, the electrical and logical connection to the PLC with the PLC interface. This cable consists of the following elements: PLC connection of the manufacturer. Multi-pin LIYY or LY YCY (shielded) cable with 0.14 mm² or 0.25 mm² cross-section. SubD or RSV connector for connection to the interface. The cables are automatically checked the continuity and insulation to guarantee their special functionality for which they have been developed.
