Weidmüller 1386290000 Screw terminal 35 mm² Number of pins 5 Black 1 pc(s)
EAN:
Part number:
Item no:
Product type
Screw terminal
CS
15 mm
Pins per row
5
Number of pins
5
Connection
Print
Screw terminal
Datasheet (PDF)
Highlights & Details
- Content 1 pc(s)
Technical specifications
- Type
LXXX 15.00/05/90F 4.5SN BK BX
- Product type
Screw terminal
- CS
15 mm
- No. of rows
1
- Pins per row
5
- Number of pins
5
- Series
LXXX
- Min. stripping length
18 mm
- Stripping length (max.)
18 mm
- Connection
Print
Screw terminal
- Nominal current
126 A
- Cross section (flexible) (min.)
0.5 mm²
- Nominal current - rounded value
126 A
- Cross section (inflexible) (min.)
0.5 mm²
- Cross section (flexible) (max.)
35 mm²
- Cross section (inflexible) (max.)
16 mm²
- AWG (min.)
20
- Connector orientation
Parallel (to the PCB)
- AWG max.
1
- Contact material
Cu-alloy, tin plated
- Factory colour
Black
- Weight
149.88 g
- Manufacturer part #
1386290000
- Content
1 pc(s)
- Nominal voltage
600 V
- Width
105 mm
- Height
56 mm
- Length
31 mm
- Type
LXXX 15.00/05/90F 4.5SN BK BX
- UKCA
yes
