Name: Weidmüller 1397370000 PCB connector Total number of pins 4 100 pc(s)
Brand: Weidmüller
SKU: 1949197

Green three-pin connector, side view. Used for electrical connections in devices.

Product type

PCB connector

Total no. of pins

5.08 mm

Content

100 pc(s)

Total number of pins

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Highlights & Details

Total number of pins 4
Content 100 pc(s)

Our service for you

Technical specifications

Depth: 8.5 mm
PCB mounting: THT solder connection
Outlet angle: 180°
Number of solder pins per pin: 1
Insulating material: PA GF
Storage temperature: -25 °C to +55 °C.
Insertion force/pole 10 N.
Pulling force/pole: 7.5 N.
Solder pin length 3.2 mm

Product type: PCB connector

Total no. of pins: 4

Total number of pins: 4

CS: 5.08 mm

Nominal current: 18.5 A

Nominal current - rounded value: 18.5 A

Connection: THT
Soldering

Factory colour: Green

Case material: PA

Manufacturer part #: 1397370000

Content: 100 pc(s)

Contact material: CuMg

Width: 23.52 mm

Height: 15.2 mm

Max. temperature: +100 °C

Min. temperature: -50 °C

Type: SL 5.08HC/04/180G 3.2SN GN BX

Dim: (W x H) 23.52 mm x 15.2 mm

Resistance: 5 mΩ

Insulation resistance: 100 MΩ

Connector contact surface: Tin plated

Dimensions: 23.52 mm x 15.2 mm x 8.5 mm

Nominal voltage: 300 V

Number of pins: 4

RoHS-compliant: Yes

Mating cycles: 25

Pin length: 3.2 mm

UKCA: not relevant

Variants(All information is without VAT, plus shipping costs)

Nominal current - rounded value

Content

Total no. of pins

Weidmüller 1095680000 PCB connector Total number of pins 2 No. of rows 1 60 pc(s)

Item no:1952041

Unavailable

Conrad Electronic

20 A

60 pc(s)

7.62 mm

Piece(s)

Minimum order quantity: 1

Multiple: 1

Weidmüller 1095700000 PCB connector Total number of pins 4 No. of rows 1 35 pc(s)

Item no:1952042

Unavailable

Conrad Electronic

20 A

35 pc(s)

7.62 mm

Piece(s)

Minimum order quantity: 1

Multiple: 1

Weidmüller 1137350000 PCB connector Total number of pins 10 No. of rows 1 36 pc(s)

Item no:1952058

Unavailable

Conrad Electronic

20 A

36 pc(s)

5.08 mm

Piece(s)

Minimum order quantity: 1

Multiple: 1

Weidmüller 1210040000 PCB connector Total number of pins 7 No. of rows 2 50 pc(s)

Item no:1952090

Unavailable

Conrad Electronic

50 pc(s)

5 mm

Piece(s)

Minimum order quantity: 1

Multiple: 1

Weidmüller 1236370000 PCB connector Total number of pins 12 No. of rows 1 50 pc(s)

Item no:1952095

Unavailable

Conrad Electronic

10 A

50 pc(s)

3.81 mm

Piece(s)

Minimum order quantity: 1

Multiple: 1

Weidmüller 1277290000 PCB connector Total number of pins 8 No. of rows 1 132 pc(s)

Item no:1952113

Unavailable

Conrad Electronic

9.5 A

132 pc(s)

3.5 mm

Piece(s)

Minimum order quantity: 1

Multiple: 1

Weidmüller 1277330000 PCB connector Total number of pins 14 No. of rows 1 72 pc(s)

Item no:1949914

Unavailable

Conrad Electronic

9.5 A

72 pc(s)

3.5 mm

Piece(s)

Minimum order quantity: 1

Multiple: 1

Weidmüller 1277390000 PCB connector Total number of pins 26 No. of rows 1 36 pc(s)

Item no:1949354

Unavailable

Conrad Electronic

9.5 A

36 pc(s)

3.5 mm

Piece(s)

Minimum order quantity: 1

Multiple: 1

Weidmüller 1277420000 PCB connector Total number of pins 30 No. of rows 1 30 pc(s)

Item no:1951094

Unavailable

Conrad Electronic

9.5 A

30 pc(s)

3.5 mm

Piece(s)

Minimum order quantity: 1

Multiple: 1

Weidmüller 1277460000 PCB connector Total number of pins 4 No. of rows 1 264 pc(s)

Item no:1949355

Unavailable

Conrad Electronic

9.5 A

264 pc(s)

3.5 mm

Piece(s)

Minimum order quantity: 1

Multiple: 1
