Weidmüller 1505060000 PCB connector Total number of pins 4 60 pc(s) Box
EAN:
Part number:
Item no:
Product type
PCB connector
Total no. of pins
4
Connector type
Socket
CS
7.62 mm
Content
60 pc(s)
Datasheet (PDF)
Highlights & Details
PCB connector (conductor connection), 800 V, 15 A, pitch in mm: 7.62, 3.31 mm², pin number: 4, bracket connection, box
- Content 60 pc(s)
Technical specifications
- Packaging type
Box
- Product type
PCB connector
- Total no. of pins
4
- Connector type
Socket
- Connector orientation
Parallel (to the PCB)
- CS
7.62 mm
- Nominal current
12.5 A
- Nominal current - rounded value
12.5 A
- Connection
Screws
- Factory colour
Green
- Case material
Plastic
- Manufacturer part #
1505060000
- Content
60 pc(s)
- Contact material
Copper
- Max. temperature
100 °C
- Min. temperature
-50 °C
- Type
BLZ 7.62/04/90 SN GN BX
- Nominal voltage
800 V
- Number of pins
4
- Cross section
2.5 mm²
Flexible PCB-connector
Green
800 V
4
Bus
Plastic
Uncoated
-50-100 °C
8 kV
6021
Screw connection
III
2
Tubular cable
7.62 mm
7.62 mm
0.2-2.5 mm²
0.2-2.5 mm²
0.2-2.5 mm²
Polybutylene terephthalate
Copper
180° (horizontal)
12.5 A
V0
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 3749953 Weidmüller 1505060000 PCB connector Total number of pins 4 60 pc(s) Box
User & Safety Instructions
User & Safety Instructions 3749953 Weidmüller 1505060000 PCB connector Total number of pins 4 60 pc(s) Box
Description
Pluggable PCB connection with innovative connection technology for safe and intuitive use.
