Weidmüller 1715050000 Screw terminal 1.5 mm² Number of pins 3 Black 100 pc(s) Piece
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Screw terminal
CS
3.5 mm
Pins per row
3
Number of pins
3
Highlights & Details
- Content 100 pc(s)
Our service for you
Technical specifications
- 45°/135° PCB/conductor connection angle (angled upwards)Pin length 4.5 mmProtection class, mounted: IP20Number of floors: 1Dimensioning surge voltage: 2.5 kVOperating temperature: -50 °C - +100 °COvervoltage category IIPollution level: 2Flammability class of the insulating material according to UL 94: V2
- Packaging type
Piece
- Type
LM 3.50/03/135 4.5SN BK BX
- Product type
Screw terminal
- CS
3.5 mm
- No. of rows
1
- Pins per row
3
- Number of pins
3
- Stripping length (max.)
5 mm
- Connection
Screws
Soldering
THT
- Nominal current
10 A
- Cross section (flexible) (min.)
0.5 mm²
- Nominal current - rounded value
10 A
- Cross section (inflexible) (min.)
0.5 mm²
- Cross section (flexible) (max.)
1.5 mm²
- Cross section (inflexible) (max.)
1.5 mm²
- AWG (min.)
28
- Connector orientation
At an angle (to the PCB)
- AWG max.
14
- Contact material
Cu-alloy, tin plated
- Enclosure material
Polyamide
- Factory colour
Black
- Manufacturer part #
1715050000
- Content
100 pc(s)
- Nominal voltage
300 V
- Height
17.2 mm
- Length
4.5 mm
