Weidmüller 1720590002 ETO SM 27/18 TRANSPAR. Device markers Fitting type: Adhesive Writing area: 18 x 27 mm Transparent
EAN:
Part number:
Item no:
Product type
Device markers
Fitting type
Adhesive
Writing area length
18 mm
Writing area width
27 mm
Type
ETO SM 27/18 TRANSPAR.
Datasheet (PDF)
Highlights & Details
Protective film multi-card
Our service for you
Technical specifications
- Depth: 0.2 mm
- Net weight: 11.2 g
- flammability class according to UL 94: HB
- adhesive: Permanent acrylic copolymer
- Type
ETO SM 27/18 TRANSPAR.
- Product type
Device markers
- Fitting type
Adhesive
- Writing area length
18 mm
- Writing area width
27 mm
- Writing area
18 x 27 mm
- Material
Polyester
- Suited for series
Devices and appliances
Universal usage
22mm switches
- Features
with protective coating
- Series
ETO
- Min. temperature
-20 °C
- Max. temperature
+80 °C
- Factory colour
Transparent
- No. of markers
1120
- Labels per sheet
112
- Dim
(L x W x H) 18 x 27 x 18 mm
- Industrial packaging
Yes
- Content
10 pc(s)
- Width
27 mm
- Height
18 mm
- Length
18 mm
- RoHS-compliant
Yes
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 356276 Weidmüller 1720590002 ETO SM 27/18 TRANSPAR. Device markers Fitting type: Adhesive Writing area: 18 x 27 mm Transparent
User & Safety Instructions
User & Safety Instructions 356276 Weidmüller 1720590002 ETO SM 27/18 TRANSPAR. Device markers Fitting type: Adhesive Writing area: 18 x 27 mm Transparent
Description
Device marker multi-card. 18 x 27 mm, polyester film, Color: transparent. SM is a multi-card markers for the identification of Command and warning devices. The signs are locked in the holder or with the pre-applied adhesive film. With the labeling systems PrintJet PRO, Plotter, MCP Plus, MCP Basic or MC Mobilo can be used to create individual labels. Demand-driven and fast in-house production. No storage of expensive standard signs are required. High-resistant print quality with the PrintJet as engraving replacement. For extreme demands, we recommend the protective film ETO SM. Holder can be used for pushbutton Ø 22 mm from Siemens, ABB, Moeller and telemecanique.
This text is machine translated.
This text is machine translated.
