Weidmüller 1724680000 Screw terminal 4 mm² Number of pins 2 Orange 100 pc(s)
EAN:
Part number:
Item no:
Product type
Screw terminal
CS
9.52 mm
Pins per row
2
Number of pins
2
Connection
Print
Screw terminal
Datasheet (PDF)
Highlights & Details
Screw terminal block
Our service for you
Technical specifications
- Type
LL 9.52/02/90 5.0SN OR BX
- Product type
Screw terminal
- CS
9.52 mm
- No. of rows
1
- Pins per row
2
- Number of pins
2
- Series
LL
- Min. stripping length
7 mm
- Stripping length (max.)
7 mm
- Connection
Print
Screw terminal
- Nominal current
30 A
- Cross section (flexible) (min.)
0.22 mm²
- Nominal current - rounded value
30 A
- Cross section (inflexible) (min.)
0.18 mm²
- Cross section (flexible) (max.)
4 mm²
- Cross section (inflexible) (max.)
6 mm²
- AWG (min.)
26
- Connector orientation
Parallel (to the PCB)
- AWG max.
10
- Contact material
Cu-alloy, tin plated
- Factory colour
Orange
- Wire protection
Yes
- Actuation direction
Perpendicular (to the PCB)
- Weight
6.46 g
- Manufacturer part #
1724680000
- Industrial packaging
Yes
- Content
100 pc(s)
- Nominal voltage
300 V
- Width
19.64 mm
- Height
26.5 mm
- Length
12.5 mm
- Type
LL 9.52/02/90 5.0SN OR BX
- UKCA
not relevant
