Weidmüller 1786440000 Screw terminal 4 mm² Number of pins 10 Orange 1 pc(s)
EAN:
Part number:
Item no:
Product type
Screw terminal
CS
7.62 mm
Pins per row
10
Number of pins
10
Connection
Print
Screw terminal
Datasheet (PDF)
Highlights & Details
Screw terminal block
Our service for you
Technical specifications
- Type
TOP4GS10/90 7.62 OR
- Product type
Screw terminal
- CS
7.62 mm
- No. of rows
1
- Pins per row
10
- Number of pins
10
- Series
TOP
- Min. stripping length
13 mm
- Stripping length (max.)
13 mm
- Connection
Print
Screw terminal
- Nominal current
30 A
- Cross section (flexible) (min.)
0.5 mm²
- Nominal current - rounded value
30 A
- Cross section (inflexible) (min.)
0.5 mm²
- Cross section (flexible) (max.)
4 mm²
- Cross section (inflexible) (max.)
6 mm²
- AWG (min.)
26
- Connector orientation
Parallel (to the PCB)
- AWG max.
10
- Contact material
Cathode copper, tin plated
- Factory colour
Orange
- Wire protection
Yes
- Actuation direction
Parallel (to the PCB)
- Weight
80.52 g
- Manufacturer part #
1786440000
- Industrial packaging
Yes
- Content
1 pc(s)
- Nominal voltage
300 V
- Width
77.7 mm
- Height
29.5 mm
- Length
26 mm
- Type
TOP4GS10/90 7.62 OR
