Weidmüller 1839290000 Screw terminal 16 mm² Number of pins 4 Pebble grey 20 pc(s)
EAN:
Part number:
Item no:
Product type
Screw terminal
CS
10.16 mm
Pins per row
4
Number of pins
4
Connection
Print
Screw terminal
Datasheet (PDF)
Highlights & Details
Screw terminal block
- Content 20 pc(s)
Our service for you
Technical specifications
- Type
LUP 10.16/04/90 3.2SN GY BX
- Product type
Screw terminal
- CS
10.16 mm
- No. of rows
1
- Pins per row
4
- Number of pins
4
- Series
LUP
- Min. stripping length
12 mm
- Stripping length (max.)
12 mm
- Connection
Print
Screw terminal
- Nominal current
58 A
- Cross section (flexible) (min.)
0.5 mm²
- Nominal current - rounded value
58 A
- Cross section (inflexible) (min.)
0.5 mm²
- Cross section (flexible) (max.)
16 mm²
- Cross section (inflexible) (max.)
16 mm²
- AWG (min.)
22
- Connector orientation
Parallel (to the PCB)
- AWG max.
6
- Contact material
Cathode copper, tin plated
- Factory colour
Pebble grey
- Wire protection
Yes
- Actuation direction
Perpendicular (to the PCB)
- Weight
38.65 g
- Manufacturer part #
1839290000
- Industrial packaging
Yes
- Content
20 pc(s)
- Nominal voltage
300 V
- Width
41.44 mm
- Height
34.7 mm
- Length
25.1 mm
- Type
Lob 10.16/04/90 3.2SN GY BX
- UKCA
not relevant
