Weidmüller 2562150000 PCB connector Total number of pins 8 1 pc(s)
EAN:
Part number:
Item no:
Product type
PCB connector
Total no. of pins
8
CS
1.27 mm
Content
1 pc(s)
Total number of pins
8
Datasheet (PDF)
Highlights & Details
- Total number of pins 8
- Content 1 pc(s)
Technical specifications
- Depth: 16.8 mm
- Mounting on circuit board: THT/THR soldering connection
- Outlet angle: 180°
- Number of solder pins per pin: 1
- Insulation material PA 9T
- Storage temperature: -40 °C to +85 °C.
- Protection class: IP20
- Contact base material: Phosphor bronze
- Voltage resistance contact 1000 V/DC
- LED: Yes
- Colour LED left: Green / yellow
- Colour LED right: Green / yellow
- Shielding material: Brass
- Data transfer rate up to 10/100 Mbit/s.
- Product type
PCB connector
- Total no. of pins
8
- Total number of pins
8
- CS
1.27 mm
- Nominal current
1.5 A
- Nominal current - rounded value
1.5 A
- Connection
THT
THR
Soldering
- Factory colour
Black
- Case material
PA
- Manufacturer part #
2562150000
- Content
1 pc(s)
- Width
16 mm
- Height
18.9 mm
- Max. temperature
+85 °C
- Min. temperature
-40 °C
- Type
RJ45M R1V 1.9N4YG/YG RL
- Dim
(W x H) 16 mm x 18.9 mm
- Insulation resistance
500 MΩ
- Connector contact surface
Au
- Dimensions
16 mm x 18.9 mm x 16.8 mm
- Nominal voltage
125 V
- Number of pins
8
- RoHS-compliant
Yes
- Mating cycles
750
- UKCA
yes
