Weidmüller 2640180000 PCB connector Total number of pins 20 1 pc(s) Box
EAN:
Part number:
Item no:
Product type
PCB connector
Total no. of pins
20
Connector type
Socket
CS
3.5 mm
Content
1 pc(s)
Datasheet (PDF)
Highlights & Details
PCB connector (conductor connection), 160 V, 8 A, pitch in mm: 3.50, 1.5 mm², pin number: 20, bracket connection, box
- Content 1 pc(s)
Technical specifications
- Packaging type
Box
- Product type
PCB connector
- Total no. of pins
20
- Connector type
Socket
- Connector orientation
Parallel (to the PCB)
- CS
3.5 mm
- Connection
Screws
- Factory colour
Green
- Case material
Plastic
- Manufacturer part #
2640180000
- Content
1 pc(s)
- Contact material
Copper silver plated
- Max. temperature
105 °C
- Min. temperature
-40 °C
- Type
CPS 3.50/20/90 SN GN BX
- Connector contact surface
Tin
- Nominal voltage
160 V
- Number of pins
20
- Cross section
1.5 mm²
Flexible PCB-connector
Green
160 V
20
Bus
Plastic
Uncoated
-40-105 °C
2.5 kV
6021
Screw connection
Tin
III
2
Tubular cable
3.5 mm
3.5 mm
0.2-1 mm²
0.2-0.75 mm²
0.2-1 mm²
0.05-1.5 mm²
Polyamide (PA)
Copper
180° (horizontal)
V0
Documents & Downloads
Datasheet
Datasheet 3767165 Weidmüller 2640180000 PCB connector Total number of pins 20 1 pc(s) Box
User & Safety Instructions
User & Safety Instructions 3767165 Weidmüller 2640180000 PCB connector Total number of pins 20 1 pc(s) Box
Description
Pluggable PCB connection with innovative connection technology for safe and intuitive use.
