Image similar
Weidmüller 2650560000 Screw terminal 1 mm² Number of pins 15 Green 128 pc(s) Piece
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Screw terminal
CS
3.81 mm
Pins per row
15
Number of pins
15
Highlights & Details
Our service for you
Technical specifications
- PCB angle/conductor connection 0°/180° (horizontal)Pin length 3.5 mmNumber of floors: 1Dimensioning surge voltage: 2.5 kVOperating temperature: -40 °C - +105 °COvervoltage category IIPollution level: 2Flammability class of the insulating material according to UL 94: V0
- Packaging type
Piece
- Type
TCS 3.81/15/90 3.5SN GN BX
- Product type
Screw terminal
- CS
3.81 mm
- No. of rows
1
- Pins per row
15
- Number of pins
15
- Stripping length (max.)
5 mm
- Connection
Screws
Soldering
THT
- Nominal current
10 A
- Cross section (flexible) (min.)
0.2 mm²
- Nominal current - rounded value
10 A
- Cross section (inflexible) (min.)
0.2 mm²
- Cross section (flexible) (max.)
1 mm²
- Cross section (inflexible) (max.)
1.5 mm²
- AWG (min.)
26
- Connector orientation
Parallel (to the PCB)
- AWG max.
16
- Contact material
Cu-alloy, tin plated
- Enclosure material
Polyamide
- Factory colour
Green
- Manufacturer part #
2650560000
- Content
128 pc(s)
- Nominal voltage
150 V
- UKCA
not relevant
