Weidmüller FS 4CO Relay socket Compatible with series: Weidmüller D-S DRM series (L x W x H) 60 x 30.6 x 70 mm 10 pc(s)
Product type
Relay socket
Connection
Screws
Mounting type
DIN rail
Content
10 pc(s)
Factory colour
Black
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
Relay socket
Our service for you
Technical specifications
- Wire stripping length rated connection 7 mm
- Tightening torque, max.: 0.8 Nm
- Flammability class according to UL 94: V-0
- Continuous current 10 A
- Clamping range, max. 2.5 mm²
- Creepage and air distance input - output: ≥ 4 mm
- Storage temperature: -40 °C…70 °C
- Conductor connection: M3 spade terminal (insulated)
- Conductor cross-section, single-wire, max. 2.5 mm²
- Conductor cross-section, fine strand, max. 2.5 mm²
- Nominal switching voltage 250 V AC
- STANDARDS: EN 60664-1:2007, EN 61000-6-2:2005, EN 61000-6-4:2007 + A1:2011, UL 508
- Product Note: The Protection Module (RC Filter) RIM 3 110/230VAC LED, part no. 7760056045, is not compatible with this socket. There is no cross connection available for this socket.
- Switching voltage AC, max. 300 V
- Voltage strength input - output: 2 kVeff / 1 min.
- Surge voltage 4 kV (1.2/50 µs)
- Depth: 28.9 mm
- Overvoltage category II
- Pollution level: 2
- Product type
Relay socket
- Content
10 pc(s)
- Factory colour
Black
- Connection
Screws
- Mounting type
DIN rail
- Contact type
4 change-overs
- Industrial packaging
Yes
- Weight
48.1 g
- Compatible with
Weidmüller
- Compatible with series
Weidmüller D-S DRM series
IP10
- Min. temperature
-40 °C
- Max. temperature
+70 °C
- Width
30.6 mm
- Height
70 mm
- Length
60 mm
- Dim
(L x W x H) 60 x 30.6 x 70 mm
- RoHS-compliant
Yes
- Type
FS 4CO
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 391067 Weidmüller FS 4CO Relay socket Compatible with series: Weidmüller D-S DRM series (L x W x H) 60 x 30.6 x 70 mm 10 pc(s)
User & Safety Instructions
User & Safety Instructions 391067 Weidmüller FS 4CO Relay socket Compatible with series: Weidmüller D-S DRM series (L x W x H) 60 x 30.6 x 70 mm 10 pc(s)
Description
Relay socket for relays of the DRM series from Weidmüller.
