Weidmüller HDC 06B KLU 1M25G 1021330000 Connector enclosure 1 pc(s)
EAN:
Part number:
Item no:
Product type
Connector enclosure
Thread size
M25
Case material
Aluminium, die cast
Type
HDC 06B KLU 1M25G
Series
RockStar® HDC 06B
Datasheet (PDF)
Highlights & Details
HDC enclosures, Size: 3, Protection degree: IP 65, Coupling housing, End-locking clamp, lower side, Standard, Size of cable entries: M 25
- HDC06B KLU 1M 25G
Technical specifications
- Wide housing C: 43 mm
- Height Housing B: 54.8 mm
- Length Housing: 60 mm
- Tightening torque: 1.2 Nm
- EMC Housing: No
- Surface: Powder coating
- Material Locking element: Stainless steel, stainless
- steel Number of cable input above: 1
- Number of cable input side: 0
- Design type: Standard
- size: 3
- Bracket design: Suitable for
- ModulPlug®: No
- Size of cable inputs: M 25
- Top/bottom part/cover: Lower part
- of seal: NBR
- Type
HDC 06B KLU 1M25G
- Product type
Connector enclosure
- Series
RockStar® HDC 06B
- Manufacturer part #
1021330000
- Features
+ longitudinal brace on the bottom part
Cable input (straight)
+ thread
- Thread size
M25
- Case material
Aluminium, die cast
- Factory colour
Grey
- Weight
150 g
- Content
1 pc(s)
- Width
66 mm
- Height
55 mm
- Length
74 mm
IP65
- Max. temperature
+125 °C
- Min. temperature
-40 °C
66
FALSE
55 mm
Grey
Single locking lever
0
FALSE
TRUE
Aluminium
Powder coating
-40-125 °C
Other
TRUE
Coupling housing
IP65
Aluminium
Two-sided
Base unit
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 195703 Weidmüller HDC 06B KLU 1M25G 1021330000 Connector enclosure 1 pc(s)
User & Safety Instructions
User & Safety Instructions 195703 Weidmüller HDC 06B KLU 1M25G 1021330000 Connector enclosure 1 pc(s)
Description
The special die-cast alloy and the multi-layered surface sealing provide complete protection for the HDC housings.
The cleverly designed interlock system is manufactured from stainless steel. This guarantees a long lifespan with high resistance to corrosion and impact.
The housing interlock system provides integrated safety. Our unique, patented spring system provides the housing interlock with a secure grip and prevents accidental opening.
The laser marking allows for easy and quick identification. Each housing is permanently labelled with a laser marking so that each product can be quickly designated and positioned.
Weidmüller RockStar® IP 65 / NEMA Type 4X housings - your first choice for industrial housings with IP 65 protection.
The cleverly designed interlock system is manufactured from stainless steel. This guarantees a long lifespan with high resistance to corrosion and impact.
The housing interlock system provides integrated safety. Our unique, patented spring system provides the housing interlock with a secure grip and prevents accidental opening.
The laser marking allows for easy and quick identification. Each housing is permanently labelled with a laser marking so that each product can be quickly designated and positioned.
Weidmüller RockStar® IP 65 / NEMA Type 4X housings - your first choice for industrial housings with IP 65 protection.
